872359 AIR VENT HEAD JIS 5KG FLANGED, WITH SCREEN #53PW-200 200MM

872359 AIR VENT HEAD JIS 5KG FLANGED, WITH SCREEN #53PW-200 200MM
规格参数 参数值
IMPA编码 872359
产品单位 PCE
产品规格 Automatic closing system by disk float, and applicable to ballast tanks or oil tanks, etc. Main body is made of grey iron casting (FC-200). Connection flanges specifications are based on JIS 5 kgf/cm2. Application of IACS (International Association of Classification Societies) unified requirements P3 (1991), and approved by NK, ABS, LRS, DNV and BV. Please specify the flange size to be connected with type of pipe head when ordering. Model: 53PW (with Screen)
中文汉化 872359 空气通风头，JIS 5公斤法兰，带筛网 #53PW-200 200毫米 自动关闭系统通过碟片浮动，适用于压载舱或油箱等。主体由灰铸铁（FC-200）制成。法兰连接规格基于JIS 5公斤/平方厘米的压力等级。 符合国际船级社协会（IACS）统一要求P3（1991），并已获得NK、ABS、LRS、DNV和BV的认证。下订单时，请指定与管道头连接的法兰尺寸。型号：53PW（带筛网）
物料版本
